PRINTER COMPATIBILITY
MakerBot METHOD X
SPOOL TYPE
Smart Spool™ provides valuable information including material type, color, and amount remaining via an RFID chip directly to MakerBot Print, while a desiccant in the spool maintains a low moisture level inside the drawer bay.
MATERIAL DATA
Heat Deflection @ 66 psi - ASTM 648: 84°C (183°F)
Flexural Strength (Method 1, 0.05”/min): 65 MPa (9,427 psi)
Flexural Modulus (Method 1, 0.05”/min): 77 Mpa (11,200 psi)
Tensile Strength at yield ((Type 1, 0.125”, 0.2”/min): 43 Mpa (6,236 psi)
Tensile Modulus (ISO 527): 2,400 MPa (348,090 psi)
Strain at Yield - Elongation (%): 2.6%
Notched Impact Strength (ASTM D256): 26 J/m (0.48 ft-lb/in)
DIMENSIONS AND WEIGHT
Spool Diameter: 21.8 cm (8.6 in)
Spool Width: 4.2 cm (1.65 in)
Material Diameter: 1.75 mm
Shipping Weight: 1.1 kg (2.4 lb)
Net Weight: 0.65 kg (1.43 lb)
STORAGE ENVIRONMENT
Store in the included a vacuum-sealed metalized polyester bag to avoid moisture absorption from air; long-term exposure to humidity can compromise material quality and performance. Make sure the built-in desiccant is in the spool to absorb any moisture exposure during the material loading process.
