Description
Product Specification
Scan Mode
Structed Light Scan
Point Distance
0.1 mm ~ 3 mm
Light Source
Infrared VCSEL structured light
Working Distance
Effective Working Distance: 160mm-1400mm Optimal Working Distance: 400mm
Depth of Field
160-1400mm
Maximum FOV
434mm*379mm (under optimal work distance)
* EINSTAR infrared light source, certificated as Class 1 laser product, is safe under all conditions of normal use.
* Global Markers alignment is only available in Object Scan Mode.
* EINSTAR must require computer equipped with NIVIDA graphics card.
